Eos series, under the name of “God Eos”, is a most typical 2V large capacity VRLA battery in Narada, it has four generations and widely implemented in field where large batteries needed. With patent terminal sealing, Lid sealing & Safety valve, Eos series is installed horizontal, and bring a lot of benefits, e.g., less footprint, easy installation & maintenance, long life. Eos series is mainly designed as standby power for Telecom, Datacenter, Utilities, and Uninterruptible power supplier.

Technical Features

• AGM-Acid Valve-Regulated Lead Acid battery

• Patent precise Terminal glue sealing & ABS Heat sealing
• Horizontal installation position for less space, easy installation & maintenance
• Soft & hard connector with complete insulation and maintenance access hole
• Self-regulating pressure relief valve with flame arrester
• Flame retardant ABS case (UL94 V-0, optional)
• Low self-discharge rate
• High gas recombination efficiency (>99%)
• Customized rack design for up to 9-class or Zone 4 application
• Comply with IEC, IEEE, UL, EN, CE standards, etc.
• Design life at 25°C (77°F): 15+ years

Main Applications

• Telecommunication

• UPS

• Power plant and power transformer system

• Navigation aid signaling system

• Solar energy system

• Radio and broadcasting station

• Emergency lighting system

• Other standby and cyclic systems

General Specifications
Type Nominal Voltage(V) Rated Capacity(Ah) Dimensions(mm) Weight

(Kg)

C10(1.80Vpc @25℃) Length Width Height Total Height

Eos-200

2V

200

94.5

184.5

360.5

372

13.5

Eos-300

2V

300

123

184.5

360.5

372

18.5

Eos-400

2V

400

166

184.5

360.5

372

24.5

Eos-500

2V

500

194.5

184.5

360.5

372

30.5

Eos-600

2V

600

223

184.5

360.5

372

35.0

Eos-800

2V

800

154

229

555

566

52.0

Eos-1000

2V

1000

186

229

555

566

62.0

Eos-1200

2V

1200

225

229

555

566

75.0

Eos-1500

2V

1500

265.5

229

555

566

92.0

Eos-2000

2V

2000

349

233

555

566

121.0

Eos-3000A

2V

3000

496

363

361.7

373.5

175.0

Range summary

EosG series, is an AGM-Polymer-Gel battery developed from Eos Series, also under the name of “God Eos Gel type”, is a most typical 2V large capacity VRLA battery in Narada, widely implemented in field where large batteries needed. With patent terminal sealing, Lid sealing & Safety valve, Eos series is installed horizontal, and bring a lot of benefits, e.g., less footprint, easy installation & maintenance, long life. Eos series is mainly designed as standby power for Telecom, Datacenter, Utilities, and Uninterruptible power supplier.

Technical Features

• Polymer-Gel Valve-Regulated Lead Acid battery

• Patent precise Terminal glue sealing & ABS Heat sealing
• Horizontal installation position for less space, easy installation & maintenance
• Soft & hard connector with complete insulation and maintenance access hole
• Self-regulating pressure relief valve with flame arrester
• Flame retardant ABS case (UL94 V-0, optional)
• Low self-discharge rate
• High gas recombination efficiency (>99%)
• Customized rack design for up to 9-class or Zone 4 application
• Comply with IEC, IEEE, UL, EN, CE standards, etc.
• Design life at 25°C (77°F): 15+ years

Main Applications

• Telecommunication

• UPS

• Power plant and power transformer system

• Navigation aid signaling system

• Energy storage system

• Radio and broadcasting station

• Emergency lighting system

• Other standby and cyclic systems

General Specifications
Type Nominal Voltage Rated
Capacity(Ah)
Dimensions(mm) Weight
(Kg)
C10 (1.80Vpc @25℃) Length Width Height Total Height

EosG200

2V

200

94.5

184.5

360.5

372

13.5

EosG300

2V

300

123

184.5

360.5

372

18.5

EosG400

2V

400

166

184.5

360.5

372

24.5

EosG500

2V

500

194.5

184.5

360.5

372

30.5

EosG600

2V

600

223

184.5

360.5

372

35.0

EosG800

2V

800

154

229

555

566

52.0

EosG1000

2V

1000

186

229

555

566

62.0

EosG1200

2V

1200

225

229

555

566

75.0

EosG1500

2V

1500

265.5

229

555

566

92.0

EosG2000

2V

2000

349

233

555

566

121.0

EosG3000A

2V

3000

496

363

361.7

373.5

175.0
